CAT CLASS: 0410457

10" x 8" High Head Silent Pump


Featuring extreme flow technology and an environmentally safe priming system, our diesel high head pumps are capable of handling flows at significantly higher TDH ratings than standard trash pumps. These units are well suited for quarries and force mains, as well as other high head applications where the TDH requirement exceeds 75 feet. In addition, they offer indefinite run-dry capabilities, meaning you don’t have to worry about your pump seizing.


Products are subject to availability.

Model 10" HH QF
Consump# Full Load 10 GPH
Dry Weight 9,600 lbs.
Engine John Deere 201 HP
Max GPM 4000
Max Head 360 '
Onboard Fuel Cap 120 gal.
Overall Dimensions 188"L x 85"W 79"H
Run Time Full Load 12 hrs.
Suction x Discharge 10" x 8"

Safety information

Safety Requirements
  • Eye Protection
  • Gloves
