CAT CLASS:
1050820
15,000 CFM Desiccant Dehumidifier Dual Fuel
Overview
Desiccant dehumidifiers utilize a solid desiccant rotor that is slowly rotated by a drive motor. As the rotor turns, this 15,000 CFM unit produces very dry discharge air with extremely low relative humidity, which is ducted to the area being treated to facilitate drying or other moisture control applications.
Specifications
Products are subject to availability.
| Make | Concepts |
| Model | MS15000TRI |
| Air Volume | 15,000-17,000 |
| Electric Load_(Electric Reactivation)_230V, 1ø | NA |
| Electric Load_(Electric Reactivation)_460V, 3ø | 335A/300 kW1 |
| Electric Load_Gas Reactivation)_460V, 3ø | 44A/56 kW1 |
| Fuel Consumption _(Natural Gas)_Max Usage | 1,200 cu. ft./hr. |
| Fuel Consumption_(Propane)_Max Usage | 127 gal./hr. |
| Moisture Removal_40°F / 80% RH | 697 gal./day |
| Moisture Removal_55°F / 80% RH | 1,022 gal./day |
| Moisture Removal_80°F / 60% RH | 1,221 gal./day |
| Overall Dimensions | 211"L x 88"w x 104"H |
| Static Pressure | 5" |
| Type Reactivation | Tri-Fuel |
| Weight | 13500 lbs |
Safety information
Safety Requirements
- Eye Protection
- Gloves
