CAT CLASS:
0880514
100 Ton Pancake Locknut Cylinder Lpl1002
Overview
Hydraulic cylinder offers a directional force through strokes of the piston rod. Produces continuous movements for constant use of force. Equipped with a safety lock nut to secure loads mechanically. Cylinder is ideally used in confined or small spaces. Made with heavy-duty alloy steel body for durability. Offers a 100 ton capacity while providing a 1.97’’ stroke.
Specifications
Products are subject to availability.
| Make | Enerpac | Enerpac |
| Model | LPL1002 | CLL-1002 |
| Capacity | N.A. | 100 ton |
| Collapsed Height | 7.3600 " | 7.3600 " |
| Extended Height | 9.3300 " | 9.3300 " |
| Matching Hand Pump | P-462 | P-462 |
| Outside Diameter | 6.5" | 6.5" |
| Stroke | 1.9700 " | 1.9700 " |
| Weight | 68 lbs | 68 lbs |
Safety information
Safety Requirements
- Eye Protection
- Gloves
