45-49K Hydraulic Excavator
Overview
For tough digging applications, the 45-49K hydraulic excavator provides powerful digging forces, swing torques and lift capacities. Crawler excavators are some of the most powerful and efficient movers and lifters on the job. This machine is an ideal option for medium to larger jobs where productivity is a priority. The full size excavator offers digging depths of up to 22 feet. In addition, the hydraulic excavator has a maximum reach of 32 feet and an increased lift capacity of 14,500 lbs.
Specifications
Products are subject to availability.
| Make | JCB | John Deere | Kobelco |
| Model | JS220LC | 210GLC | SK210LC |
| HP | 172 | 159 | 143 |
| Max Digging Depth | 21.6667 ' | 21.9167 ' | 22 ' |
| Max Digging Reach | 32.4167 ' | 32 ' | 32 ' |
| Overall Width | 118" | 126" | 126" |
| Standard Bucket | 39" 1 cu. yd. | 42" 1-1/8 cu. yd. | 36" 1-1/8 cu. yd. |
| Weight | 49450 lbs | 50463 lbs | 47000 lbs |
Safety information
Safety Requirements
- Hard Hat
- Safety Shoes
