CAT CLASS: 0580624

60' Straight Manlift

Overview

The 60' straight manlift is ideal for outdoor construction and industrial applications where extensive reach is required. The lift can reach full elevation in less than 70 seconds. The 60' boom lift has a platform height of 60' and a maximum working height of 66', as well as, a horizontal outreach of 50'. The platform measures 96" x 36" providing ample working space. Further, the restricted platform capacity of 1,000 lbs and unrestricted capacity of 500 lbs allows for multiple workers with tools and supplies at the same time for optimal efficiency on the job. In addition, the lift also features a 110V AC receptacle in the basket for a convenient power source at working height. Lastly, it is important to wear a safety harness while operating aerial lifts.

Specifications

Products are subject to availability.

Make Genie JLG
Model S-60 D 4WD 600S D 4WD
Fuel Type Diesel Diesel or dual fuel
Gradeability 45% 45%
Horizontal Reach 50.8333 ' 49.5000 '
Platform Height 60 ' 60 '
Platform Size 96" x 36" 96" x 36"
Restricted Platform Capacity 1000 lbs 1000 lbs
Transport Width 98 " 95 "
Unrestricted Platform Capacity 500 lbs 500 lbs
Weight 21380 lbs 25100 lbs

Safety information

Safety Requirements
  • Safety Harness
  • Wallet (Training Card)
