CAT CLASS:
0070002
24' Push Around Single Manlift
Overview
The single man lift is designed to effortlessly move around the job site and to vertically gain access to those tight workspaces. This push type lift is built for reliability and strength, but is also easy to set-up and simple to operate. The lift has a platform height of 25' and a maximum working height of 31’. This model's platform measures 26" x 26". Further, the platform capacity is up to 350 lbs allowing for a single operator with tools and supplies. The machine weighs approximately 970 lbs making it convenient to transport. This single man lift easily fits through a standard doorway. Additionally, these lifts also feature a standard 110V AC receptacle in the platform for an accessible power source at working height. Lastly, it is important to wear a safety harness while operating aerial lifts.
Specifications
Products are subject to availability.
| Make | Genie | JLG |
| Model | AWP-25S | 25AM |
| Overall Dimensions | 52"L x 29"W | 49"L x 29"W |
| Platform Capacity | 350 lbs | 350 lbs |
| Platform Height | 25 ' | 25 ' |
| Platform Size | 27" x 26" | 26" x 26" |
| Power Source | Push | Push |
| Stowed Height | 78" | 78" |
| Weight | 817 lbs | 905 lbs |
Safety information
Safety Requirements
- Safety Harness
- Wallet (Training Card)
