CAT CLASS:
0810640
5 Ton Beam Trolley
Overview
This 5 ton beam trolley provides a convenient means to suspend chain hoists from an overhead beam and provide horizontal travel. The trolley adjusts easily to fit any beam flange within range. Dual tread wheels allow use on flat or tapered flange beams and the wheels run on sealed ball bearings for long life and low maintenance. The trolley has a minimum beam height of 6.9", minimum curve radius 60" and weighs 93 lbs.
Specifications
Products are subject to availability.
Make | Coffing | Harrington Hoist |
Model | CBTP0500 | PTF2050 |
Capacity | N.A. | 5 ton |
Min Beam _Height | 6 " | 6.9000 " |
Min Curve_Radius | 70.8700 " | 60 " |
Std Flange _Adjustment | 3.55" - 8.67" | 4.5" - 8" |
Type | Push | Push |
Weight | N.A. | 93 lbs. |
Safety information
Safety Requirements
- Eye Protection
- Hard Hat
- Gloves
- Safety Shoes
