CAT CLASS: 0810630

3 Ton Beam Trolley

Overview

This 3 ton beam trolley provides a convenient means to suspend chain hoists from an overhead beam and provide horizontal travel. The trolley adjusts easily to fit any beam flange within range. Dual tread wheels allow use on flat or tapered flange beams and the wheels run on sealed ball bearings for long life and low maintenance.

Specifications

Products are subject to availability.

Make Jet General Clamp Harrington Hoist
Model 3HGT B-1 PTF2030
Capacity N.A. N.A. 3 ton
Min Beam _Height 8 " 8 " 6.2000 "
Min Curve_Radius 51 " 55 " 48 "
Std Flange _Adjustment 4-8 in 3" - 8" 3.9" - 8"
Type Push Push Push
Weight 53 lbs 52 lbs. 60 lbs.

Safety information

Safety Requirements
  • Eye Protection
  • Hard Hat
  • Gloves
  • Safety Shoes
